Description

Meter Interface (MI) with Seal & Plug

80-911-0005-00

The Meter Interface accepts inputs from external AC and DC power metering sensors such as: AC and DC voltage and amps, AC kWatts, and DC battery capacity in amp hours and % remaining. All feature high and low alarms that can be set by the user.

AC

• 3 x AC voltage inputs (multi voltage)
• 2 x AC current inputs
• Calculates true RMS power

DC

• 3 x DC voltage inputs (multi voltage)
• 2 x DC current inputs
• Calculates battery capacity as ampere hours and percentage charge remaining
• Resolution for current metering down to 0.1 A

General

• Outputs standard NMEA 2000 power monitoring sentences

Note: High and low alarm levels can be set for all inputs.
